deutz allis lawn tractors 1916
 | 1988 - 1990
Ultima SeriesGarden tractorSimplicity built | 1988 - 1990 | Ultima Series | Garden tractor | Simplicity built |
|---|---|---|---|---|---|
1988 - 1990 | |||||
Ultima Series | |||||
Garden tractor | |||||
Simplicity built | |||||
1988 - 1990 | |
|---|---|
Ultima Series | |
Garden tractor | |
Simplicity built |
Production | |
|---|---|
Distributor | Deutz-Allis |
Manufacturer | Simplicity |
Garden tractor | |
Deutz-Allis 1916 Engine | |
|---|---|
16HP Kohler 588cc 1-cyl gasoline | |
Fuel tank | 4.25 gal
16.1 L |
Engine details ...  | |
Deutz-Allis 1916 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Photos | |
|---|---|
 | |
Deutz-Allis 1916 photos...  |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Weight | 955 lbs
433 kg |
Full dimensions and tires ...  | |
Deutz-Allis 1916 attachments | |
|---|---|
42" mid-mount mower deck | |
48" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Lawn & Garden Riding Equipment published in 1988, by Deutz-Allis |
