fiat g170
 | 1993 - 2002
G SeriesRow-Crop tractor | 1993 - 2002 | G Series | Row-Crop tractor |
|---|---|---|---|---|
1993 - 2002 | ||||
G Series | ||||
Row-Crop tractor | ||||
1993 - 2002 | |
|---|---|
G Series | |
Row-Crop tractor |
Series map: G170G190126.8kw141.7kw
Note: the Fiat model G170 is the same as the Ford 8670. The following data is from the 8670 listing. |
|---|
Production | |
|---|---|
Manufacturer | Fiat |
Row-Crop tractor | |
Built in Winnipeg, Manitoba, Canada | |
Original price was $84,500 in 2000 | |
Fiat G170 Engine | |
|---|---|
Ford 7.5L 6-cyl diesel | |
Engine details ...  |
Fiat G170 Transmissions | |
|---|---|
16-speed full power shift | |
32-speed creeper | |
Transmission details ...  |
Fiat G170 Power | |
|---|---|
Engine | 170 hp
126.8 kW |
PTO (claimed) | 145 hp
108.1 kW |
Drawbar (tested) | 132.1 hp
98.5 kW |
PTO (tested) | 167.6 hp
125.0 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two- or four-wheel drive | |
Power steering | |
Wet disc brakes | |
Cab standard with air-conditioning. |
Capacity | |
|---|---|
Fuel | 110 gal
416.4 L |
Hydraulic system | 30.9 gal
117.0 L |
Front hubs | 1.7 qts (each)
1.6 L |
Front diff. | 13 qts
12.3 L |
Hydraulics | |
|---|---|
Type | closed center load sensing |
Capacity | 30.9 gal
117.0 L |
Pressure | 2750 psi
189.6 bar |
Valves | 3 |
Pump flow | 24 gpm
90.8 lpm |
Total flow | 31 gpm
117.3 lpm |
| 55 gpm (MegaFlow optional)
208.2 lpm |
Tractor hitch | |
|---|---|
Rear Type | III |
Rear lift | 10000 lbs
4536 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet disc |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@1878 |
| 1000@1903 |
Dimensions & Tires | |
|---|---|
Wheelbase | 118.3 inches
300 cm |
| 122.6 inches (SuperSteer)
311 cm |
Weight | 15800 to 18200 pounds |
Front tire | 14L-16.1 |
Rear tire | 18.4R42 |
Full dimensions and tires ...  | |
Fiat G170 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 130 |
Batteries | 2 |
Battery CCA | 950 |
Battery volts | 12 |
References | |
|---|---|
 | |
G170, G190, G210, G240 - The Pride of the Field published in 1994, by Fiat |
