massey ferguson 2705
 | 1978 - 1983
2000 SeriesRow-Crop tractor | 1978 - 1983 | 2000 Series | Row-Crop tractor |
|---|---|---|---|---|
1978 - 1983 | ||||
2000 Series | ||||
Row-Crop tractor | ||||
1978 - 1983 | |
|---|---|
2000 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Massey Ferguson |
Row-Crop tractor | |
Original price was $40,000 in 1983 | |
Massey Ferguson 2705 Engine | |
|---|---|
Perkins 5.8L 6-cyl diesel | |
Fuel tank | 87 gal
329.3 L |
Engine details ...  | |
Massey Ferguson 2705 Transmissions | |
|---|---|
24-speed 3-speed power shift | |
8-speed mechanical shuttle | |
Transmission details ...  |
Massey Ferguson 2705 Power | |
|---|---|
PTO (claimed) | 120 hp
89.5 kW |
Drawbar (tested) | 101.44 hp
75.6 kW |
PTO (tested) | 122.20 hp
91.1 kW |
Performance test details ...  | |
Mechanical | |
|---|---|
Two-wheel drive | |
Final drives | planetary |
Steering | hydrostatic power |
Differential hydraulic wet disc brakes | |
Cab standard with air-conditioning. Available platform configuration with four-post ROPS. | |
Photos | |
|---|---|
 | |
Massey Ferguson 2705 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Valves | 2 or 3 |
Pump flow | 16.5 gpm (high-pressure)
62.5 lpm |
| 6.4 gpm (low-pressure)
24.2 lpm |
| 16.5 gpm (aux. high-pressure)
62.5 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position control and lower-link draft sensing |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | hydraulic |
Rear PTO Type | 540/1000 (1.375) |
Engine RPM | 540@1990 |
| 1000@2090 |
Dimensions & Tires | |
|---|---|
Wheelbase | 105.4 inches
267 cm |
Weight | 11200 to 12595 pounds |
Front tire | 9.5L-15 |
Rear tire | 16.9-38 |
Full dimensions and tires ...  | |
Massey Ferguson 2705 attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
2705 Serial Numbers | |
|---|---|
Location: | Serial number plate to the left of the tractor's instrument panel. |
1978 | 9R000733 |
1979 | 9R003482 |
1980 | 9R007282 |
1981 | 9R010307 |
1982 | 9R013230 |
1983 | 9R013525 |
FAQ: How to read a serial number table. | |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 58 |
Batteries | 2 |
Battery volts | 12 |
References | |
|---|---|
 | |
Loaders and Spreaders published in 1979, by Massey Ferguson | |
MF 2000 Series Tractors published in 1982, by Massey Ferguson |
