mccormick intl ct55u
 | 2008 - 2010
CTU SeriesCompact Utility tractor | 2008 - 2010 | CTU Series | Compact Utility tractor |
|---|---|---|---|---|
2008 - 2010 | ||||
CTU Series | ||||
Compact Utility tractor | ||||
2008 - 2010 | |
|---|---|
CTU Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | McCormick Intl (a part of Argo) |
Compact Utility tractor | |
McCormick Intl CT55U Engine | |
|---|---|
Mitsubishi 2.5L 4-cyl diesel | |
Fuel tank | 15.85 gal
60.0 L |
Engine details ...  | |
McCormick Intl CT55U Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
McCormick Intl CT55U Power | |
|---|---|
Engine | 47 hp
35.0 kW |
PTO (claimed) | 44 hp
32.8 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Steering | hydrostatic power |
Wet disc brakes | |
ROPS. Cab optional. | |
Hydraulics | |
|---|---|
Valves | 2 |
Pump flow | 9.1 gpm
34.4 lpm |
Steering flow | 4.7 gpm
17.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Rear lift (at ends) | 3,300 lbs
1496 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 |
Dimensions & Tires | |
|---|---|
Wheelbase | 74 inches
187 cm |
Weight | 5,005 lbs
2270 kg |
Full dimensions and tires ...  | |
McCormick Intl CT55U attachments | |
|---|---|
front-end loader | |
backhoe | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
CT Series published in 2008, by McCormick |
