mccormick intl ctj23
 | 2009 - 2014
CTJ SeriesCompact Utility tractor | 2009 - 2014 | CTJ Series | Compact Utility tractor |
|---|---|---|---|---|
2009 - 2014 | ||||
CTJ Series | ||||
Compact Utility tractor | ||||
2009 - 2014 | |
|---|---|
CTJ Series | |
Compact Utility tractor |
Production | |
|---|---|
Manufacturer | McCormick Intl |
Compact Utility tractor | |
McCormick Intl CTJ23 Engine | |
|---|---|
Mitsubishi 1.1L 3-cyl diesel | |
Fuel tank | 6.6 gal
25.0 L |
Engine details ...  | |
McCormick Intl CTJ23 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
McCormick Intl CTJ23 Power | |
|---|---|
Engine | 23 hp
17.2 kW |
PTO (claimed) | 18.5 hp
13.8 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | mechanical rear |
Power steering | |
Wet disc brakes | |
Two-post folding ROPS. | |
Hydraulics | |
|---|---|
Type | open center |
Valves | 1 |
Pump flow | 4.5 gpm
17.0 lpm |
Total flow | 7.1 gpm
26.9 lpm |
Steering flow | 2.6 gpm
9.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | I |
Control | position control |
Rear lift (at ends) | 1433 lbs
650 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540 (1.375) |
Mid PTO | independent |
Mid PTO Type | 2000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 60 inches
152 cm |
Weight | 1609 lbs
729 kg |
Full dimensions and tires ...  | |
McCormick Intl CTJ23 attachments | |
|---|---|
60" mid-mount mower deck | |
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 50 |
Battery volts | 12 |
References | |
|---|---|
 | |
CTJ Series published in 2009, by McCormick |
