mccormick intl x10 90m
 | 2011 - 2014
X10 SeriesUtility tractorDaedong built | 2011 - 2014 | X10 Series | Utility tractor | Daedong built |
|---|---|---|---|---|---|
2011 - 2014 | |||||
X10 Series | |||||
Utility tractor | |||||
Daedong built | |||||
2011 - 2014 | |
|---|---|
X10 Series | |
Utility tractor | |
Daedong built |
Production | |
|---|---|
Distributor | McCormick Intl |
Manufacturer | Daedong |
Utility tractor | |
Built in South Korea | |
McCormick Intl X10.90M Engine | |
|---|---|
Perkins 4.4L 4-cyl diesel | |
Fuel tank | 33 gal
124.9 L |
Engine details ...  | |
McCormick Intl X10.90M Transmission | |
|---|---|
16-speed syncronized shuttle | |
Transmission details ...  |
McCormick Intl X10.90M Power | |
|---|---|
Engine (gross) | 91.2 hp
68.0 kW |
PTO (claimed) | 78 hp
58.2 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | rear standard |
Steering | hydrostatic power |
Wet disc brakes | |
Cab standard with air-condioning, CD player, and rear wiper. | |
Photos | |
|---|---|
 | |
McCormick Intl X10.90M photos...  |
Hydraulics | |
|---|---|
Valves | 2 or 3 |
Total flow | 22.1 gpm
83.6 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | position and draft control |
Rear lift (at 24"/610mm) | 5,290 lbs
2399 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 90.7 inches
230 cm |
Weight | 8,905 lbs
4039 kg |
Front tire | 12.4x24 |
Rear tire | 18.4x34 |
Full dimensions and tires ...  | |
McCormick Intl X10.90M attachments | |
|---|---|
front-end loader | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
X10.75M/X10.90M Cab published in 2011, by McCormick |
