mccormick intl x7 440
 | 2013 -
X7.4 SeriesRow-Crop tractor | 2013 - | X7.4 Series | Row-Crop tractor |
|---|---|---|---|---|
2013 - | ||||
X7.4 Series | ||||
Row-Crop tractor | ||||
2013 - | |
|---|---|
X7.4 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | McCormick Intl (a part of Argo) |
Row-Crop tractor | |
McCormick Intl X7.440 Engine | |
|---|---|
BetaPower 4.5L 4-cyl diesel | |
Fuel tank | 74 gal
280.1 L |
Exhaust fluid (DEF) | 10 gal
37.9 L |
Engine details ...  | |
McCormick Intl X7.440 Transmissions | |
|---|---|
24-speed four-speed power shift | |
40-speed | |
Transmission details ...  |
McCormick Intl X7.440 Power | |
|---|---|
Engine | 131 hp
97.7 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Differential lock | electro-hydraulic front and rear |
Steering | hydrostatic power |
Wet disc brakes | |
Trailer brakes | hydraulic (optional) |
| pneumatic (optional) |
Cab standard with air-conditioning. Optional electro-hydraulic cab suspension. | |
Photos | |
|---|---|
 | |
McCormick Intl X7.440 photos...  |
Hydraulics | |
|---|---|
Type | closed center |
Valves | 3 to 6 |
Pump flow | 32.5 gpm
123.0 lpm |
Steering flow | 11.6 gpm
43.9 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/IIIN |
Control | lower link draft sensing |
Rear lift | 20500 lbs
9298 kg |
Front Hitch | optional |
Front lift | 7716 lbs
3499 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Clutch | electro-hydraulic wet discs |
Rear PTO Type | 540/540E/1000/1000E (1.375) |
Front PTO | independent (optional) |
Dimensions & Tires | |
|---|---|
Wheelbase | 102.4 inches
260 cm |
Weight | 12680 lbs
5751 kg |
Front tire | 540/65R28 |
Rear tire | 650/65R38 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
