bolens g292
 | 1981 - 1985
Compact Utility tractorIseki built | 1981 - 1985 | Compact Utility tractor | Iseki built |
|---|---|---|---|---|
1981 - 1985 | ||||
Compact Utility tractor | ||||
Iseki built | ||||
1981 - 1985 | |
|---|---|
Compact Utility tractor | |
Iseki built |
Production | |
|---|---|
Distributor | Bolens |
Manufacturer | Iseki |
Compact Utility tractor | |
Variants | |
|---|---|
G292 | 2WD |
G294 | 4WD |
TS2810 | similar Iseki model |
Bolens G292 Engine | |
|---|---|
Iseki 1.5L 3-cyl diesel | |
Fuel tank | 8 gal
30.3 L |
Engine details ...  | |
Bolens G292 Transmission | |
|---|---|
8-speed | |
Transmission details ...  |
Bolens G292 Power | |
|---|---|
Engine | 29 hp
21.6 kW |
Mechanical | |
|---|---|
Two-wheel drive | |
Differential lock | mechanical standard |
Steering | manual |
Mechanical shoe brakes | |
Open operator station. Two-post ROPS (#17370) optional with optional canopy. | |
Photos | |
|---|---|
 | |
Bolens G292 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Pressure | 2130 psi
146.9 bar |
Pump flow | 5.4 gpm
20.4 lpm |
Tractor hitch | |
|---|---|
Rear Type | 1 |
Control | position and draft control |
Power Take-off (PTO) | |
|---|---|
Rear PTO | live (two-stage clutch) |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Wheelbase | 69 inches
175 cm |
Weight | 2,631 lbs
1193 kg |
Front tire | 5.00-14 |
Rear tire | 12.4x24 |
Full dimensions and tires ...  | |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Equipment Seminar published in 1982 | |
Diesel Tractors - The Work Machines published in 1980, by Bolens |
