craftsman lawn tractors 917 25661
 | 1996
Lawn tractorAYP built | 1996 | Lawn tractor | AYP built |
|---|---|---|---|---|
1996 | ||||
Lawn tractor | ||||
AYP built | ||||
1996 | |
|---|---|
Lawn tractor | |
AYP built |
Production | |
|---|---|
Distributor | Craftsman (a part of Sears) |
Manufacturer | AYP |
Lawn tractor | |
Craftsman 917.25661 Engine | |
|---|---|
15.5HP Kohler 426cc 1-cyl gasoline | |
Fuel tank | 3.5 gal
13.2 L |
Engine details ...  | |
Craftsman 917.25661 Transmission | |
|---|---|
hydrostatic | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Open operator station. |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | electric |
Dimensions & Tires | |
|---|---|
Front tire | 15x6.0-6 |
Rear tire | 20x10-8 |
Full dimensions and tires ...  | |
Craftsman 917.25661 attachments | |
|---|---|
46" mid-mount mower deck | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Charging amps | 3 (battery) |
| 5 (lights) |
Battery CCA | 240 |
Battery volts | 12 |
Battery AH | 30 |
Battery Group | U1R |
References | |
|---|---|
 | |
Craftsman Lawn and Garden Tractors published in 1996, by Sears |
