john deere 7250r
 | 2014 -
7R SeriesRow-Crop tractor | 2014 - | 7R Series | Row-Crop tractor |
|---|---|---|---|---|
2014 - | ||||
7R Series | ||||
Row-Crop tractor | ||||
2014 - | |
|---|---|
7R Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | John Deere |
Row-Crop tractor | |
Built in Waterloo, Iowa, USA | |
John Deere 7250R Engine | |
|---|---|
John Deere 9.0L 6-cyl diesel | |
Engine details ...  |
John Deere 7250R Transmissions | |
|---|---|
23-speed full power shift | |
infinitely variable transmission | |
Transmission details ...  |
John Deere 7250R Power | |
|---|---|
Engine (gross) | 250 hp
186.4 kW |
Engine (net) | 240 hp
179.0 kW |
Engine (max) | 290 hp
216.3 kW |
PTO (claimed) | 205 hp
152.9 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Final drives | inboard planetary |
Differential lock | electro-hydraulic rear |
| linked electro-hydraulic front on TLS Plus axle with brakes OptOptional |
Steering | hydrostatic power |
Hydraulic wet disc brakes | |
Cab standard with air-conditioning. AutoTrac ready | |
Capacity | |
|---|---|
E23 Fuel | 143.7 gal
543.9 L |
IVT Fuel | 155.6 gal
588.9 L |
E23 G49 tires Fuel | 148.5 gal
562.1 L |
IVT G49 tires Fuel | 160.4 gal
607.1 L |
Hydraulic system | 42.3 gal
160.1 L |
Hydraulics | |
|---|---|
Type | closed center pressure-flow compensated |
Capacity | 42.3 gal
160.1 L |
Pressure | 2958 psi
204.0 bar |
Valves | 3 to 6 |
Pump flow | 42.8 gpm*Standard 63cc pump
162.0 lpm |
| 59 gpm*Optional 85cc pump
223.3 lpm |
Rear SCV flow | 34.9 gpm
132.1 lpm |
Front SCV flow | 33.3 gpm
126.0 lpm |
Tractor hitch | |
|---|---|
Rear Type | III/IIIN |
Control | electro-hydraulic draft sensing |
Rear lift | 15200 lbs
6894 kg |
| 17300 lbsOptOptional
7847 kg |
Front Hitch | IIIN |
Front lift | 11464 lbs
5200 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 1000 (1.75) |
| 540/1000 (1.375) |
| 540E/1000/1000E (1.375) |
Engine RPM | 540@1950 |
| 540E@ 1750 |
| 1000@ 1950 |
| 1000E@ 1750 |
Front PTO | independent OptOptional |
Front PTO Type | 1000 (1.375) |
| 1000 (1.75) |
Engine RPM | 1000@1940 |
Dimensions & Tires | |
|---|---|
Wheelbase | 115.2 inches
292 cm |
Weight | 23845 lbs
10816 kg |
Front tire | 540/65R34 |
Rear tire | 650/85R38 |
Full dimensions and tires ...  | |
7250R Serial Numbers | |
|---|---|
Location: | Serial number plate on right side of tractor frame, above front axle. |
Electrical | |
|---|---|
Ground | negative |
Charging system | alternator |
Charging amps | 200 |
Batteries | 2 |
Battery CCA | 925 |
Battery volts | 12 |
Battery Group | 31 |
