MTD 050
 | 1981
Lawn tractor |
|---|---|
1981 | |
Lawn tractor | |
1981 | |
|---|---|
Lawn tractor |
Production | |
|---|---|
Manufacturer | MTD |
Lawn tractor | |
Model 131-050A was a special Golden Anniversary edition tractor to celebrate MTD's 50th year. The tractor was painted in metallic charcoal with chrome trim and gold details. | |
MTD 050 Engine | |
|---|---|
11HP Briggs & Stratton 399cc 1-cyl gasoline | |
Engine details ...  |
MTD 050 Transmission | |
|---|---|
5-speed gear | |
Transmission details ...  |
Mechanical | |
|---|---|
Two-wheel drive | |
Manual steering | |
Disc brakes | |
Open operator station. |
Photos | |
|---|---|
 | |
MTD 050 photos...  |
Power Take-off (PTO) | |
|---|---|
Mid PTO | independent |
Clutch | manual idler pulley |
Dimensions & Tires | |
|---|---|
Front tire | 15.00x6.00 |
Rear tire | 20.00x10.00 |
Full dimensions and tires ...  | |
MTD 050 attachments | |
|---|---|
44" mid-mount mower deck | |
snowblower | |
blade | |
Attachment details ...  |
Electrical | |
|---|---|
Ground | negative |
Battery volts | 12 |
References | |
|---|---|
 | |
Owner's Guide 131-050A and 131-730A (770-0870) published in 1981 | |
Lawn & Garden Tractor Accessories published in 1984, by MTD | |
MTD Parts Microfiche (770-1155) published in 1981 | |
MTD Parts Microfiche (770-2200) published in 1982 | |
Parts and Service Information Manual (770-1737) published in 1982 | |
Lawn & Garden Tractors published in 1981, by MTD |
