Zetor 10045
 | 1978 - 1987
Crystal UR2 SeriesRow-Crop tractor |
|---|---|
1978 - 1987 | |
Crystal UR2 Series | |
Row-Crop tractor | |
1978 - 1987 | |
|---|---|
Crystal UR2 Series | |
Row-Crop tractor |
Production | |
|---|---|
Manufacturer | Zetor |
Row-Crop tractor | |
Built in Brno, Czechoslovakia | |
Variants | |
|---|---|
10011 | 2WD |
10045 | 4WD |
Zetor 10045 Engine | |
|---|---|
Zetor 4.6L 4-cyl diesel | |
Engine details ...  |
Zetor 10045 Transmission | |
|---|---|
16-speed | |
Transmission details ...  |
Zetor 10045 Power | |
|---|---|
Engine | 100 hp
74.6 kW |
Mechanical | |
|---|---|
Four-wheel drive | |
Hydraulic dry disc brakes | |
Cab standard. |
Photos | |
|---|---|
 | |
Zetor 10045 photos...  |
Hydraulics | |
|---|---|
Type | open center |
Valves | 1 |
Pump flow | 8.4 gpm
31.8 lpm |
Tractor hitch | |
|---|---|
Rear Type | II |
Control | lower-link draft control |
Rear lift | 7496 lbs
3400 kg |
Power Take-off (PTO) | |
|---|---|
Rear PTO | independent |
Rear PTO Type | 540/1000 |
Dimensions & Tires | |
|---|---|
Weight | 9348 lbs
4240 kg |
Front tire | 11.2-24 |
Rear tire | 16.9-34 |
Full dimensions and tires ...  | |
