agco dt225b
 | 2009 - 2010
DT-B SeriesRow-Crop tractor | 2009 - 2010 | DT-B Series | Row-Crop tractor |
|---|---|---|---|---|
2009 - 2010 | ||||
DT-B Series | ||||
Row-Crop tractor | ||||
2009 - 2010 | |
|---|---|
DT-B Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
OECD 2497: SCR diesel CVT 4WD | |
OECD 2560: EGR diesel CVT 4WD |
OCED Tractor Test 2497 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2497 | |
|---|---|
SCR diesel CVT 4WD
October 2008 - November 2008,
Link: OCED Tractor Test 2497 file | |
PTO performance | |
Max power | 266.3 hp
198.6 kW |
Fuel use | 13.2 gal/hour
50.0 l/hour |
Power at rated engine speed | 234.0 hp
174.5 kW |
Fuel use | 12.6 gal/hour
47.7 l/hour |
Power at rated PTO speed | 256.9 hp
191.6 kW |
Fuel use | 13.3 gal/hour
50.3 l/hour |
Drawbar performance | |
Max power | 194.9 hp
145.3 kW |
Fuel use | 12.3 gal/hour
46.6 l/hour |
Pull at 8.7 KPH | |
Max pull | 30,190 lbs
13694 kg |
Pull at 3.9 KPH | |
OCED Tractor Test 2560 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2560 | |
|---|---|
EGR diesel CVT 4WD
October 2009 - March 2010,
Link: OCED Tractor Test 2560 file | |
PTO performance | |
Max power | 269.4 hp
200.9 kW |
Fuel use | 14.8 gal/hour
56.0 l/hour |
Power at rated engine speed | 238.0 hp
177.5 kW |
Fuel use | 14.6 gal/hour
55.3 l/hour |
Power at rated PTO speed | 256.1 hp
191.0 kW |
Fuel use | 14.8 gal/hour
56.0 l/hour |
Drawbar performance | |
Max power | 195.1 hp
145.5 kW |
Fuel use | 14.7 gal/hour
55.6 l/hour |
Pull at 7.6 KPH | |
Max pull | 28,325 lbs
12848 kg |
Pull at 4.0 KPH | |
