agco rt155a
 | 2006 - 2011
RT-A SeriesRow-Crop tractor | 2006 - 2011 | RT-A Series | Row-Crop tractor |
|---|---|---|---|---|
2006 - 2011 | ||||
RT-A Series | ||||
Row-Crop tractor | ||||
2006 - 2011 | |
|---|---|
RT-A Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
OECD 2202: diesel 32-speed 4WD | |
OECD 2198: diesel CVT 4WD | |
OECD 2517: diesel 24-speed 4WD | |
OECD 2421: diesel CVT 4WD |
OCED Tractor Test 2202 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2202 | |
|---|---|
Diesel 32-speed 4WD
March 2004 - June 2004,
Link: OCED Tractor Test 2202 file | |
PTO performance | |
Max power | 166.0 hp
123.8 kW |
Fuel use | 9.1 gal/hour
34.4 l/hour |
Power at rated engine speed | 156.1 hp
116.4 kW |
Fuel use | 9.6 gal/hour
36.3 l/hour |
Power at rated PTO speed | 165.2 hp
123.2 kW |
Fuel use | 9.2 gal/hour
34.8 l/hour |
Drawbar performance | |
Max power | 135.7 hp
101.2 kW |
Fuel use | 9.9 gal/hour
37.5 l/hour |
Gear 2LA used for power test. | |
Max pull | 16,150 lbs
7325 kg |
Gear 2TB used for pull test. | |
OCED Tractor Test 2198 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2198 | |
|---|---|
Diesel CVT 4WD
January 2004 - May 2004,
Link: OCED Tractor Test 2198 file | |
PTO performance | |
Max power | 168.6 hp
125.7 kW |
Fuel use | 9.5 gal/hour
36.0 l/hour |
Power at rated engine speed | 157.0 hp
117.1 kW |
Fuel use | 10.2 gal/hour
38.6 l/hour |
Power at rated PTO speed | 166.8 hp
124.4 kW |
Fuel use | 10.0 gal/hour
37.9 l/hour |
Drawbar performance | |
Max power | 125.1 hp
93.3 kW |
Fuel use | 10.1 gal/hour
38.2 l/hour |
Pull at 7.52 KPH | |
Max pull | 16,995 lbs
7708 kg |
Pull at 4.33 KPH | |
OCED Tractor Test 2517 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2517 | |
|---|---|
Diesel 24-speed 4WD
January 2009 - April 2009,
Link: OCED Tractor Test 2517 file | |
PTO performance | |
Power at rated engine speed | 165.8 hp
123.6 kW |
Fuel use | 10.1 gal/hour
38.2 l/hour |
Power at rated PTO speed | 196.3 hp
146.4 kW |
Fuel use | 10.5 gal/hour
39.7 l/hour |
Drawbar performance | |
Max power | 136.0 hp
101.4 kW |
Fuel use | 9.5 gal/hour
36.0 l/hour |
Gear 3A used for power test. | |
Max pull | 21,445 lbs
9727 kg |
Gear 1A used for pull test. | |
OCED Tractor Test 2421 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 2421 | |
|---|---|
Diesel CVT 4WD
June 2007 - September 2007,
Link: OCED Tractor Test 2421 file | |
PTO performance | |
Max power | 190.0 hp
141.7 kW |
Fuel use | 10.3 gal/hour
39.0 l/hour |
Power at rated engine speed | 162.5 hp
121.2 kW |
Fuel use | 9.7 gal/hour
36.7 l/hour |
Power at rated PTO speed | 185.7 hp
138.5 kW |
Fuel use | 10.2 gal/hour
38.6 l/hour |
Drawbar performance | |
Max power | 118.9 hp
88.7 kW |
Fuel use | 9.3 gal/hour
35.2 l/hour |
Pull at 9.51 KPH | |
Max pull | 19,930 lbs
9040 kg |
Pull at 3.13 KPH | |
