agco allis 9695
 | 1994 - 1998
9600 SeriesRow-Crop tractor | 1994 - 1998 | 9600 Series | Row-Crop tractor |
|---|---|---|---|---|
1994 - 1998 | ||||
9600 Series | ||||
Row-Crop tractor | ||||
1994 - 1998 | |
|---|---|
9600 Series | |
Row-Crop tractor |
OCED Tractor Test 1700 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1700 | |
|---|---|
Diesel 18-speed 4WD
September 8 - 21, 1995
Link: OCED Tractor Test 1700 file | |
PTO performance | |
Max power | 211.46 hp
157.7 kW |
Fuel use | 12.0 gal/hour
45.4 l/hour |
Power at rated engine speed | 196.57 hp
146.6 kW |
Fuel use | 12.1 gal/hour
45.8 l/hour |
Power at rated PTO speed | 204.47 hp
152.5 kW |
Fuel use | 12.1 gal/hour
45.8 l/hour |
Drawbar performance | |
Max power | 170.15 hp
126.9 kW |
Fuel use | 12.2 gal/hour
46.2 l/hour |
Gear 11 used for power test. | |
Max pull | 17583 lbs
7975 kg |
Gear 6 used for pull test. | |
