craftsman lawn tractors 917 25483
 | 1981 - 1982
FF SeriesGarden tractorRoper built | 1981 - 1982 | FF Series | Garden tractor | Roper built |
|---|---|---|---|---|---|
1981 - 1982 | |||||
FF Series | |||||
Garden tractor | |||||
Roper built | |||||
1981 - 1982 | |
|---|---|
FF Series | |
Garden tractor | |
Roper built |
Engine Detail | |
|---|---|
Onan T260G | |
gasoline | |
2-cylinder | |
air-cooled opposed-twin | |
Displacement | 983 cc
60 ci |
Bore/Stroke | 3.56x3.00 inches
90 x 76 mm |
Power (gross) | 24 hp
17.9 kW |
Rated RPM | 3600 |
Starter | electric |
Starter volts | 12 |
Sparkplug gap | 0.025 inches
0.635 mm |
Point gap | 0.016 inches
0.406 mm |
Engine Oil | |
|---|---|
 | |
Oil capacity | 3 qts
2.8 L |
Oil change | 25 h |
