farmall a

OverviewEngineTransmissionDimensionsTestsPhotos
Farmall A tractor photo
1939 - 1947 Row-Crop tractor
1939 - 1947
Row-Crop tractor
1939 - 1947
Row-Crop tractor
1939 - 1947
Row-Crop tractor
Tractor Tests
NTTL 329: gasoline 4-speed 2WD
NTTL 330: distillate 4-speed 2WD
Nebraska Tractor Test 329
A fuel use from test 329
A fuel use from test 329
A fuel use from test 329
A fuel use from test 329
Nebraska Tractor Test 329
Gasoline 4-speed 2WD September 28 - October 6, 1939 Link: Nebraska Tractor Test 329 file
Belt power (max)
18.34 hp 13.7 kW
Belt fuel use (max)
1.6 gal/hour 6.1 l/hour
Drawbar performance
Max power
16.32 hp 12.2 kW
Gear 2 used for power test.
Max pull
2,387 lbs 1082 kg
Gear 1 used for pull test.
Nebraska Tractor Test 330
A fuel use from test 330
A fuel use from test 330
A fuel use from test 330
A fuel use from test 330
Nebraska Tractor Test 330
Distillate 4-speed 2WD October 9 - 16, 1939 Link: Nebraska Tractor Test 330 file
Belt power (max)
16.51 hp 12.3 kW
Belt fuel use (max)
1.4 gal/hour 5.3 l/hour
Drawbar performance
Max power
15.17 hp 11.3 kW
Gear 2 used for power test.
Max pull
2,360 lbs 1070 kg
Gear 1 used for pull test.
