j i case 1194
 | 1983 - 1984
94 SeriesUtility tractor | 1983 - 1984 | 94 Series | Utility tractor |
|---|---|---|---|---|
1983 - 1984 | ||||
94 Series | ||||
Utility tractor | ||||
1983 - 1984 | |
|---|---|
94 Series | |
Utility tractor |
Nebraska Tractor Test 1378 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1378 | |
|---|---|
Diesel 12-speed 2WD
March 27 - April 9, 1981
Link: Nebraska Tractor Test 1378 file | |
PTO performance | |
Power at rated engine speed | 43.09 hp
32.1 kW |
Fuel use | 2.9 gal/hour
11.0 l/hour |
Power at rated PTO speed | 38.54 hp
28.7 kW |
Fuel use | 2.6 gal/hour
9.8 l/hour |
Drawbar performance | |
Max power | 34.65 hp
25.8 kW |
Fuel use | 2.8 gal/hour
10.6 l/hour |
Gear 4-1 used for power test. | |
Max pull | 4620 lbs
2095 kg |
Gear 1-3 used for pull test. | |
