j i case 2290
 | 1979 - 1983
90 SeriesRow-Crop tractor | 1979 - 1983 | 90 Series | Row-Crop tractor |
|---|---|---|---|---|
1979 - 1983 | ||||
90 Series | ||||
Row-Crop tractor | ||||
1979 - 1983 | |
|---|---|
90 Series | |
Row-Crop tractor |
Tractor Tests | |
|---|---|
NTTL 1296: diesel 8-speed 2WD | |
NTTL 1297: diesel 12-speed 2WD |
Nebraska Tractor Test 1296 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1296 | |
|---|---|
Diesel 8-speed 2WD
November 7, 1978 - January 4, 1979
Link: Nebraska Tractor Test 1296 file | |
PTO performance | |
Power at rated engine speed | 128.80 hp
96.0 kW |
Fuel use | 8.9 gal/hour
33.7 l/hour |
Drawbar performance | |
Max power | 106.07 hp
79.1 kW |
Fuel use | 8.5 gal/hour
32.2 l/hour |
Gear 3L used for power test. | |
Max pull | 12,635 lbs
5731 kg |
Gear 1H used for pull test. | |
Nebraska Tractor Test 1297 | ||
|---|---|---|
 | | |
| ||
|
|---|
Nebraska Tractor Test 1297 | |
|---|---|
Diesel 12-speed 2WD
November , - January 4, 1979
Link: Nebraska Tractor Test 1297 file | |
PTO performance | |
Power at rated engine speed | 129.08 hp
96.3 kW |
Fuel use | 8.9 gal/hour
33.7 l/hour |
Drawbar performance | |
Max power | 109.21 hp
81.4 kW |
Fuel use | 8.6 gal/hour
32.6 l/hour |
Gear 3I used for power test. | |
Max pull | 12,749 lbs
5782 kg |
Gear 2L used for pull test. | |
