oliver 1950 t

OverviewEngineTransmissionDimensionsTestsAttachmentsPhotos
Oliver 1950-T tractor photo
1967 - 1969 50 SeriesRow-Crop tractor
1967 - 1969
50 Series
Row-Crop tractor
1967 - 1969
50 Series
Row-Crop tractor
1967 - 1969
50 Series
Row-Crop tractor
Tractor Tests
NTTL 969: diesel Hydaul-Shift 2WD
NTTL 972: diesel Hydraul-Shift 4WD
Nebraska Tractor Test 969
1950-T fuel use from test 969
1950-T fuel use from test 969
1950-T fuel use from test 969
1950-T fuel use from test 969
Nebraska Tractor Test 969
Diesel Hydaul-Shift 2WD November 13 - 18, 1967 Link: Nebraska Tractor Test 969 file
PTO performance
Power at rated engine speed
105.24 hp 78.5 kW
Fuel use
6.5 gal/hour 24.6 l/hour
Drawbar performance
Max power
70.07 hp 52.3 kW
Fuel use
4.9 gal/hour 18.5 l/hour
Gear 4-Under used for power test.
Max pull
12,884 lbs 5844 kg
Gear 1-Over used for pull test.
Nebraska Tractor Test 972
1950-T fuel use from test 972
1950-T fuel use from test 972
1950-T fuel use from test 972
1950-T fuel use from test 972
Nebraska Tractor Test 972
Diesel Hydraul-Shift 4WD April 29 - May 7, 1968 Link: Nebraska Tractor Test 972 file
PTO performance
Power at rated engine speed
105.11 hp 78.4 kW
Fuel use
6.5 gal/hour 24.6 l/hour
Drawbar performance
Max power
89.10 hp 66.4 kW
Fuel use
6.6 gal/hour 25.0 l/hour
Gear 3-Direct used for power test.
Max pull
17,692 lbs 8025 kg
Gear 1-Direct used for pull test.
