new holland 4630
 | 1994 - 1999
30 SeriesUtility tractor | 1994 - 1999 | 30 Series | Utility tractor |
|---|---|---|---|---|
1994 - 1999 | ||||
30 Series | ||||
Utility tractor | ||||
1994 - 1999 | |
|---|---|
30 Series | |
Utility tractor |
Series map: 39304630503050.0hp*60.0hp68.9hp*4630↓ 1990-1993*Estimated engine power for comparison only.
Note: the New Holland model 4630 is the same as the Ford 4630. The following data is from the 4630 listing. |
|---|
Tractor Tests | |
|---|---|
OECD 1645: 3.3L diesel 8-speed 4WD | |
OECD 1703: 3.1L diesel 16-speed 4WD |
OCED Tractor Test 1645 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1645 | |
|---|---|
3.3L diesel 8-speed 4WD
April 30 - May 3, 1991
Link: OCED Tractor Test 1645 file | |
PTO performance | |
Power at rated engine speed | 55.41 hp
41.3 kW |
Fuel use | 3.7 gal/hour
14.0 l/hour |
Power at rated PTO speed | 50.77 hp
37.9 kW |
Fuel use | 3.2 gal/hour
12.1 l/hour |
Drawbar performance | |
Max power | 46.47 hp
34.7 kW |
Fuel use | 3.7 gal/hour
14.0 l/hour |
Gear 2H used for power test. | |
Max pull | 4,833 lbs
2192 kg |
Gear 3L used for pull test. | |
OCED Tractor Test 1703 | ||
|---|---|---|
 | | |
| ||
|
|---|
OCED Tractor Test 1703 | |
|---|---|
3.1L diesel 16-speed 4WD
October 23 - 27, 1995
Link: OCED Tractor Test 1703 file | |
PTO performance | |
Power at rated engine speed | 56.82 hp
42.4 kW |
Fuel use | 3.7 gal/hour
14.0 l/hour |
Power at rated PTO speed | 53.12 hp
39.6 kW |
Fuel use | 3.2 gal/hour
12.1 l/hour |
Drawbar performance | |
Max power | 48.54 hp
36.2 kW |
Fuel use | 3.7 gal/hour
14.0 l/hour |
Gear 6L used for power test. | |
Max pull | 5,672 lbs
2572 kg |
Gear 3L used for pull test. | |
