new holland 7740
 | 1996 - 1997
PowerStar 40 SeriesRow-Crop tractor | 1996 - 1997 | PowerStar 40 Series | Row-Crop tractor |
|---|---|---|---|---|
1996 - 1997 | ||||
PowerStar 40 Series | ||||
Row-Crop tractor | ||||
1996 - 1997 | |
|---|---|
PowerStar 40 Series | |
Row-Crop tractor |
Series map: TS110↑ 1999-200366407740784090.7hp100.3hp100.0hp*7740↓ 1991-1995*Estimated engine power for comparison only.
Note: the New Holland model 7740 is the same as the Ford 7740. The following data is from the 7740 listing. |
|---|
Engine Detail | |
|---|---|
Ford Genesis | |
turbocharged diesel | |
4-cylinder 8-valve | |
liquid-cooled | |
The 7740 used a Lucas CAV DP200 fuel pump. | |
Displacement | 304 ci
5.0 L |
Bore/Stroke | 4.40x5.00 inches
112 x 127 mm |
Power (net) | 95 hp
70.8 kW |
Power (gross) | 100.3 hp
74.8 kW |
Air cleaner | dual paper elements |
Compression | 17.5:1 |
Rated RPM | 2100 |
Idle RPM | 725-2275 |
Torque | 413 lb-ft
560.0 Nm |
Torque RPM | 1200 |
Firing order | 1-3-4-2 |
Starter volts | 12 |
ROPS Coolant capacity | 15.3 qts
14.5 L |
Cab Coolant capacity | 16.9 qts
16.0 L |
Intake valve clearance | 0.016 inches (cold)
0.406 mm |
Exhaust valve clearance | 0.019 inches (cold)
0.483 mm |
Engine Oil | |
|---|---|
 | |
Oil capacity | 12.1 qts
11.5 L |
